K-Curtain

LED Curtain Display
K-Curtain

The grid screen series is specially designed for outdoor fixed installation, and is widely used in building exterior wall, road advertisement and so on. Compared with the traditional products, the grid screen series is thinner, the brightness is higher, and the IP67 grade is waterproof and dustproof, so that most of the outdoor adverse weather can be met. And the front and back maintenance is supported, and the structural cost and the labor cost are saved.

Ultra light weight

Ultra light weight

Easy maintenance

Easy maintenance

Fast installation

Fast installation

10m-50m

10m-50m

4,000-7,500nits

4,000-7,500nits

Transparency>60%

Transparency>60%

High protection grade

  • High protection level: IP67.
  • The surface of lamp bar PCB is moisture-proof, waterproof and corrosion-proof by technical treatment.
  • The lamp bar uses flame retardant silicone dissolved silica gel to achieve waterproof treatment.

Energy saving, power consumption only 1/3 of the conventional

 High brightness and high efficiency, can be customized 15000cd/m2 high brightness screen.

Ultra Slim and Thin Design

Thinnest part only 12mm, light to 16kg/sqm. It is 60% lighter & 50% thinner than traditional displays. Reduce massive load-bearing for installation, saving cost on transportation and installation. Permeability and low wind resistance, good for cooling and day lighting. Ventilation ensures strong wind load capacity, fan-less.

K-Curtain-Series Specifcations
 Model No. K-CT 10 K-CT 16 K-CT 31.25 K-CT 50
  Pixel Pitch(mm) 8.34x12.5 16.67x16.67 31.25x31.25 50x50
  LED Arrangement SMD3535 SMD3535 SMD3535 SMD3535
  Pixel Density(pixels/m²) 9,600 3,600 1,240 400
 Cabinet Dimensions(mm) 1000x500 1000x500 1000x1000 1000x1000
 Transparency 30% 45% 70% 80%.
  Max. Consumption 600W/m² 600W/m² 550W/m² 550W/m²
  Ave. Consumption 180W/m² 180W/m² 180W/m² 180W/m²
 Brightness   6500nits  5500nits   5000nits 3000nits
 Brightness level 256Level 256Level 256Level 256Level
 Installation
Outdoor
 Operating Life
≥100,000hours
 Certificate
CE, ROHS, FCC

Application places

The installation of led rental display is convenient and quick, and the display is quickly spliced between the cabinets. It is mainly used for stage, wedding venues, large shopping malls, hotels and other short-term display occasions
